HV Stackable Rack

Power your world with HV Stackable Rack - Unleashing Innovation and Performance!

For Data Sheet Click here

Description

Applications

  • Renergy Power established in 2016 in the United Kingdom, is a leading manufacturer of premium Lithium-ion and VRLA batteries. We were founded to meet the increasing demand for efficient and sustainable energy storage solutions.
  • Our batteries are engineered for diverse applications, ranging from renewable energy systems to industrial equipment, serving both residential and commercial needs. With a strong focus on innovation, reliability, and environmental sustainability, Renergy Power is dedicated to delivering long-lasting, high-performance batteries that help build a greener, more connected future.
  • HV Stackable Rack
  • HV-S20kwh offers 16.07Kwh High Voltage.

Key Features

image1-14.34

Safe & Reliable

  • Lithium batteries offer greater safety and longer lifespan. - two-level structure, intelligent management, and multiple protection.
  • Battery pack with active cell balancing can match at will battery module -Support wide voltage 100-700V - Support max 5 pcs system in parallel.

image3-14.34

Modular Design, Flexible Expansion

  • Each battery module has a capacity of 16.07kWh. - Supporting 4~12 standard modules in series. - Matching single-phase and three-phase energy storage inverters.

image2-14.34

Easy installation and maintenance

  • Standard modular stackable design and rack for easy installation and maintenance.

System Composition Parameter

ItemsParameters
High Voltage Box80~850Vdc
Working Voltage Range(V)204.8V~614.4V
Nominal Charge and Discharge Current(A)200/200
Maximum Charge and Discharge Current(A)200A
Operating Temperature Range(℃)-20~60
IP RatingIP20
Dimension(W/D/H,mm)460*760*208
Approximate Weight(kg)27
ItemsParameters
Lithium Iron Phosphate Battery-51.2V314Ah Battery TypeLiFePO4
Nominal Voltage(V)51.2
Rated Capacity(Ah)314
Rated Energy(kWh)16.07kWh
Recommended Charge and Discharge Current(A)100A
Max Charge/Discharge Current(A)200A
Charging Temperature Storage Temperature-20~55℃
IP RatingIP20
Dimension(W/D/H,mm)460*760*260
Approximate Weight(kg)120

Product Details

Technical Specifications
ItemsDescription
Chemistry Nominal Energy (kWh)LiFePO4
Nominal Voltage (V)51.2
Module Capacity(Ah)314
Allowed Modules in Series12
System Nominal Voltage (V)4810
OperatingVoltageRange (V)204.8409.6512
System Energy (kWh)64.32128.64160.7
Charging Current(A)Maximum Charging Current：200A Recommended Charging Current：100A
Discharging Current(A)Maximum Discharge Current: 200A Recommended Discharge Current: 100A
Temperature（℃ )Discharging: -20~55℃ Charging: 0 ~55℃ Storage:0-45℃
Communication PortCAN/RS485
IP Rating Dimension (W/D/H, mm)IP20 (Natural Heat Dissipation)
Installation Site Storage Temperature（℃）Indoor 0-45℃ 80% 0.5C/0.5C ,25℃
Recommended Depth of Discharge80%
Cycle Life Warranty5 years
CertificationCE, UN38.3
